PEM electrolyser technical specifications

250 kW to 5 MW modular PEM systems

Combining 15 years of research and development by the CSIRO in PEM electrolysis and our team's extensive experience in hydrogen innovation, we are engineering a suite of technologies that enable the distributed on-site production of green hydrogen. Our approach is uniquely focused on making it possible to produce hydrogen where it is needed, when it is needed, even at smaller scales - eliminating the need for long-distance transportation and storage, and reducing the associated costs and environmental impacts.

Electrolyser Product Selector

Electrolyser Product Selector

Proton Exchange Membrane (PEM) Electrolysis Systems

Select your capacity to view technical specifications
System Configuration
Production
Power
Flow Rate

Technical Specifications

Select a model to view specifications
Hydrogen System
Electrolyser type Proton Exchange Membrane (PEM)
Hydrogen production rate -
-
-
Turndown range -
Hydrogen delivery pressure -
Hydrogen delivery purity 99.999%
Oxygen content in hydrogen -
Water content in hydrogen -
Water consumption 30 L/kgH₂
Power System
AC connection 380-415 V, 3 ph, 50-60 Hz
System energy consumption - BoL -
Input power (kW) - BoL -
Operating Conditions
Ambient operating temperature 5-45°C
Storage temperature 5-60°C
Hazardous area Non-hazardous area install
Water input quality Potable water
Conformity
Electrolyser AS 22734:2020
Electrical equipment AS/NZS 3000:2018
Hazardous area equipment AS/NZS 60079-14:2024
Pressure equipment AS/NZS 1200:2000

Download a copy of the PEM electrolyser specification sheet

Access full PEM electrolyser technical specifications, including power input, hydrogen production rates, efficiency and environmental conditions.
